PUZZLE

Operating rinciple

The lifting and lateral parking equipment without avoidance is generally used on the second floor. Commonly used in underground parking lots. This type of parking equipment has a loading plate for each parking space, with a non yielding loading plate at the end of the lower parking space. The non yielding platform is equipped with a driving component to achieve the movement of the non yielding platform on the ground; When the vehicle loading plate needs to be stored (retrieved), the non avoidance platform plate leaves the parking space according to the set track, allowing the remaining vehicle loading plates to reach the ground level through lifting and lateral movement. The driver parks the stored cars on the vehicle loading plate or drives out the parked cars on the vehicle loading plate to complete the retrieval process. Suitable for real estate, hospitals, subway stations, commercial centers, and other places.

Equipment parameters

Capacity specifications Sedan/SUV Number of vehicles/number of floors that can be made 2N (number of floors) -2 vehicles/4-11 floors
Vehicle pick-up time/clearance time 2nd floor for 30s Rated speed Lift 4.0-6.0m/min; Translation 6.0-8.0m/min
Lifting method Motor+chain type/wire rope type Control system PLC system
Operation method IC card+number buttons/facial recognition

CAD Structural diagram

Rendering
